The TS80 is a high-performance tilt & slide door system designed for residential and commercial applications requiring seamless indoor-outdoor transitions. With an 80mm profile depth and innovative multi-chamber thermal break technology, it delivers exceptional thermal efficiency while supporting large-format sliding panels up to 250 kg.
The tilt-before-slide operating mechanism allows the panel to be tilted inward for gentle ventilation or slid fully open along the track for wide unobstructed apertures. Engineered with a recessed threshold option, the TS80 provides barrier-free access without compromising weather performance.
| PERFORMANCE | Value |
|---|---|
| Thermal Insulation | 1.4 W/m²K |
| Acoustic Insulation | 34 dB |
| Airtightness | 4 |
| Watertightness | E750 |
| Windload | C3/B3 |
| Parameter | Value |
|---|---|
| Wall Thickness | 1.8 mm |
| Frame Depth | 80 mm |
| Panel Width, max | 2800 mm |
| Panel Height, max | 2800 mm |
| Panel Weight, max | 250 kg |
