The TF80 is a high-performance thermally broken bifold door system with an 80mm profile depth, engineered for expansive openings that demand exceptional thermal efficiency and seamless indoor-outdoor transitions. Its robust polyamide thermal break minimises heat loss while maintaining structural rigidity across wide spans.
Featuring slim sightlines, multi-point locking up to 12 points, and premium weather seals, the TF80 delivers superior airtightness and watertightness while accommodating panel weights up to 120 kg for large-format glazing configurations.
| PERFORMANCE | Value |
|---|---|
| Thermal Insulation (Uf) | 2.0 W/m²K |
| Acoustic Insulation | 37 dB |
| Airtightness | 4 |
| Watertightness | E900 |
| Windload | C5/B5 |
| Parameter | Value |
|---|---|
| Profile Depth | 80 mm |
| Wall Thickness | 1.8 mm |
| Glazing Thickness | 24 – 44 mm |
| Panel Width, max | 1200 mm |
| Panel Height, max | 3000 mm |
